- Compressor Wheel: 67.3*84.4mm(extended tip diameter: 87.3mm)
- Larger Turbine Wheel for Higher Horsepower: 74*66mm
- Compressor Inlet: 4″ Hose
- Compressor Outlet: 2.5″ Hose
- Turbine Inlet: T3 Open
- Turbine Outlet: 5 Bolt
- Turbine housing internal wastegate hole: 33mm
- Water Ports: -6AN
- Oil Feed: -4AN to the Oil Restrictor
- Oil Drain: Std T3 Oil Drain Flange
- Actuator working pressure: 15psi/10psi/5psi
Application:
Replacement for factory XR6 PT3582 PT3576 Turbos.
- 2002- BA FALCON XR6
- 2004- BF FALCON XR6
- 2008- FPV F6/TYPHOON/TORNADO
- 2006- TERRITORY
- 2008- FG FALCON XR6
- 2008- FG FALCON G6E
